Marlin Bikes

MARLIN RS18

MARLIN RS18

Regular price Rs. 71,990.00
Regular price Rs. 74,990.00 Sale price Rs. 71,990.00
Sale Sold out
Shipping calculated at checkout.
Size
Color

The Marlin RS18 offers lasting comfort, performance and all-road versatility, with a combination of ultra-light triple butted aluminium 6061 thru axle frame and carbon fork. The relaxed endurance geometry puts you in an upright road riding position to keep you comfortable on quick spins. Equipped with latest Shimano Sora drivetrain, Tektro mechanical disc brakes and durable and loud sealed bearing six pawl hubs making this mean machine a great value for money road bike

Specification:

  • FrameSet:
    • Frame: Triple Butted, smooth weld, Aluminum Alloy 6061, tapered headtube, dropper post ready, 142x12 mm thru axle
    • Fork: Marlin RS18 carbon fork, tapered alloy steerer, internal brake routing, flat mount disc, 12x100mm thru axle
    • Colour: Matt Black, Pearl White
    • Decal: Water Decal
  • Drivetrain:
    • Shifters: Shimano Sora R3000 2x9 shifter
    • Crank: Prowheel Ounce-621C-N, 50-34T
    • Cassette: Shimano Sora HG400, 11-28T, 9-speed
    • Front Derailleur: Shimano Sora R3000, 2 Speed
    • Rear Derailleur: Shimano Sora RD-R3000-SS, 9 Speed
    • Bottom Bracket: Sealed Bearing, MX-A141
    • Chain: KMC Z-9
    • Pedals: Wellgo M085, alloy cage
  • Cockpit:
    • Saddle: Spate, Light weight Saddle
    • Seat Post: Spate, Alloy, 27.5x2.2Tx300mm
    • Handle Bar: Alloy, 31.8 mm, 90 mm reach, 130 mm drop, 400 mm width
    • Head Set: Sealed cartridge bearing, 1-1/8" top, 1.5" bottom
    • Stem: Alloy Stem with 7°rise/drop, 80mm length for size 52 and 90mm for size54
  • Wheel & Tire:
    • Rims: Aluminum alloy double wall 20 hole Front and 24 hole Rear
    • F/R Hub: Solon DH-536T, 4 Sealed bearing, 6 pawl hubs
    • Spokes: Stainless Steel, G14
    • Tire & Tube: Kenda 700x28c
  • Brake Set
    • Brake: Tektro MD-C310 mechanical disc brakes
    • Rotor: Tektro rotor, 160mm



  • Accessories:
    • Tool Kit
    • Reflectors
  • Weight: 10.5 kilograms
  • Ideal Height: Size 52(168-178cm), Size 54(175-186cm)
  • Max Weight: 125 kilograms (including bike weight)



Geometry & Size:

MM

Size 52

Size 54

Height(cm)

168-178

175-186

Seat Tube Length(A)

520

540

Seat Tube Angle (B)

73

73

Head Tube Length (D)

120

120

Head Tube Angle (E)

72

72

Effective Top Tube (F)

554.7

564.7

Bb Height (G)

274

274

Bb Offset (H)

65

65

Chainstay Length (I)

425

425

Wheelbase (J)

1011.3

1011.7

Frame Reach (K)

387.1

387.1

Frame Stack (L)

548

548

Standover Height (M)

763

789
